REGUPOL sonus curve 8



ACOUSTIC UNDERLAY

_______

Mitigate Impact Sound Transmission

IDEAL FOR USE UNDER BOND APPROVED FLOOR COVERINGS:

Z

STONE

Z

MARBLE

Z

TILES

Z

SCREED BEDS (bonded & unbonded)

Z

CEMENT & PLYWOOD SHEETING

(in conjunction with selected floor coverings such as solid timber)

AVAILABLE IN

ROLL FORMAT

mm thick

VIEW

PRODUCT OVERVIEW

TEST REPORTS

CERTIFICATION

BROCHURES

PRODUCT ENQUIRY FORM

DIMENSIONS

MATERIAL

ROLL DIMENSIONS
________

LENGTH: 20lm

WIDTH: 1.15 m

SQM: 23m²

THICKNESS: 8/4 mm

WEIGHT PER ROLL: 84kg

WEIGHT PER M²: 3.65 kg

Manufactured from selected SBR rubber and recycled materials

AN ENVIRONMENTALLY PREFERABLE PRODUCT THAT MEETS  GECA 25-2001 V2.0i Floor Coverings Standard

Product Information



PRODUCT OVERVIEW

TEST REPORTS

CERTIFICATION

brochures

REGUPOL sonus curve 8

Former product name: REGUPOL 6010 8/4 mm

PRODUCT OVERVIEW

Regupol sonus curve 8 is very popular under bonded screed beds and commercial screeds and is used extensively throughout the education, retail, commercial and multi-residential building sectors.

Independently tested under laboratory controlled conditions and on-site testing to show it meets the Deemed-to-Satisfy Provisions of the current building regulations in accordance with the Building Code of Australia Part F5.4 sound Insulation Ratings of Floors (Impact).

MORE DETAILS

Regupol sonus curve 8 is finished in a dimple profile and is technically superior when it comes to bonded screed beds. The dimple profile reduces ‘impact sound’ and allows the generated noise to dissipate.

    • Offers long term performance without collapse or bottoming out.
    • Available in Rolls.
    • Minimal creep, even under high loads.
    • Resistant to ageing and deformation.
    • PVC free.
    • Made in Germany from recycled materials.
    • Quick and easy to install.
    • Minimises construction heights.
    • High quality and exact material thicknesses.
    • Suitable for use with under floor heating.
    • A Good Environmental Choice Australia Certified sustainable product (GECA)
    • Protects expansion joints.
    • Limits sound transference
    • Cushioning qualities make flooring comfortable underfoot
    • Proven durability.

ADHESIVES

Regupol adhesives are formulated to maximize the performance of Regupol flooring and acoustic products. Regupol adhesives are made in Australia and are VOC compliant for green buildings, offering specifiers and installation contractors a warranted flooring system.

Note: All applications should be checked for suitability with the selected floor finish, waterproof membranes, REGUPOL adhesives, tile adhesives, grouts etc.

INDEPENDENTLY TESTED

TEST REPORTS

Download Test Reports

UNDER ENGINEERED TIMBER

REGUPOL sonus curve 8
IIC [dB] : 53  Lnw [dB] : 57  ΔLw [dB] : 18

UNDER TILE AND SCREED

REGUPOL sonus curve 8
IIC [dB] : 59  Lnw [dB] : 50  ΔLw [dB] : 26

ENVIRONMENTALLY PREFERABLE PRODUCT

CERTIFICATION

Download Certification

REGUPOL sonus curve 8 is an environmentally preferable underlay that meets the requirements of the Good Environmental Choice Australia GECA 25-2011 v2.0i – Floor Coverings Standard.

PDF

BROCHURES

MIXED-USE BUILDINGS

TILES & SCREED

URBAN DENSIFICATION

TIMBER
