REGUPOL comfort 12



ACOUSTIC UNDERLAY

_______

Mitigate Impact Sound Transmission

IDEAL FOR USE IN:

Z

SOLID TIMBER CONSTRUCTIONS

Z

RENOVATION OF OLD BUILDINGS

Z

LIGHT TIMBER CONSTRUCTION PROJECTS

AVAILABLE IN

ROLL FORMAT

mm thick

VIEW

PRODUCT OVERVIEW

DOCUMENTS

PROPERTIES

BROCHURES

PRODUCT ENQUIRY FORM

DIMENSIONS

MATERIAL

ROLL DIMENSIONS
________

LENGTH: 9.3 m

WIDTH: 1150 mm

THICKNESS: 12mm

WEIGHT PER ROLL: 36.5kg

WEIGHT PER M²: max 3.0 kg

PUR bonded elastomers

Ideal for solid timber constructions, renovation of old buildings or light timber construction projects.

Product Information



PRODUCTS OVERVIEW

DOCUMENTS

PROPERTIES

brochures

REGUPOL COMFORT 12



PRODUCT OVERVIEW

REGUPOL comfort 12 is a versatile, 12mm thick impact sound insulation layer with a profiled underside and a low dynamic stiffness of ≤ 10 MN/m3 which is used under floating screed constructions.   REGUPOL comfort 12 is very well suited for new building construction and renovation projects, especially in solid timber constructions (CLT).

MORE DETAILS

The REGUPOL comfort range was developed for solid timber construction and refurbishment projects, in which existing installation heights can lead to limitations. The key benefits are low thicknesses between 8mm and 12mm, low dynamic stiffness values of ≤ 15 MN/m3 to ≤ 10 MN/m3 and impact sound reductions between ∆Lw 24 dB and ∆Lw 29 dB. REGUPOL comfort impact sound insulation materials are CE-certified and are subject to internal monitoring plans and those of the ETA 17/1030, as well as the high environmental and health protection requirements stipulated in German building regulations. This guarantees not only reliable planning within Germany but also worldwide.

For the renovation of old buildings and light timber construction projects, a combination of REGUPOL comfort 12, 12mm impact sound insulation, and REGUPOL comfort S1 elastically bonded levelling fill is perfect for compensating height differences and increasing the mass of the construction. Airborne and impact sound tests on C1 wood frame ceilings (EN ISO 10140-5) show that even with a 40mm thick levelling fill effective sound insulation values of Ln,w 47 dB / Rw 69 dB can be achieved.

Note: All applications should be checked for suitability with the selected floor finish, waterproof membranes, REGUPOL adhesives, tile adhesives, grouts etc.

INDEPENDENTLY TESTED

DOCUMENTS

Documents

REGUPOL comfort 12 test documentation, CAD drawings & installation instructions available on request.

PROPERTIES

properties

Properties

  • CE marking
  • Impact sound reduction ∆Lw ≥ 29 dB
  • Load bearing capacity up to 5 kN/m²
  • Compressibility ≤ 2 mm
